商品の詳細:
|
| 応用: | EVバッテリーパックBMS PCBおよびFPC用コンフォーマルコーティング | 硬化条件: | 1500 mJ/cm2 (UV) |
|---|---|---|---|
| 25℃での粘度: | 450±150mPa・s | 硬度: | 73 ショアA |
| 色: | 琥珀透明 | 絶縁耐力: | 23kV/mm |
| 特徴: | 青色蛍光で点検しやすい、低臭・低刺激 | 保管状態: | 8～28℃で6ヶ月 |
| 包装: | 1kg / 5kg | ||
| ハイライト: | UV cure adhesive for EV battery,Circuit board protection glue,Flexible printed circuits coating |
||
Circuit Board Protection Glue Description "Reliable protection, easy inspection." This circuit board protection glue (3200) is an amber transparent, solvent-free UV curing conformal coating specially developed for EV battery pack BMS boards and flexible printed circuits (FPC). It offers low hardness, low irritation and low odor for a friendly working environment, good adhesion to PCB substrates, plastics, glass and metal, and its blue fluorescence makes coating inspection
