商品の詳細:
|
| モデル: | 3523 | 色: | 青/赤透明 |
|---|---|---|---|
| 25℃での粘度: | 70000 +/- 15000 mPa.s | 硬化条件: | 600mJ/cm2 |
| 硬度: | ショアD 78D | 抗張力: | 12 MPa |
| 破断伸び: | 120% | 絶縁耐力: | 20～23kV/mmクラス |
| 貯蔵寿命: | 8～28℃で12ヶ月 | 包装: | 30g / 50g / 300g |
| 応用: | データケーブルのはんだ接合保護、TYPE-C ピンの補強 | ||
| ハイライト: | UV curing sealant for Type-C,78D hardness UV cure adhesive,Blue UV sealant pin reinforcement |
||
Product Overview 3523 is a single component, high adhesion and high hardness UV curable sealant engineered for electronic connectors and fine solder joints. The paste combines a rigid cured matrix (Shore D 78D) with strong adhesion to PVC, PC, ABS, FR-4, ceramics and metal plating, so reinforced pins survive plug and unplug cycles, cable bending and drop testing without cracking or peeling. Because it is a UV LED curing system material, 3523 reaches full handling strength in
